16´´ WYMER LYDEN CAGE FORMING H.F. TUBE MILL LINE (USED)
Specifications
| Manufacturer | Wymer Lyden |
| Condition | Used |
| Stock Number | VX-17460 |
| Hand of operation | Left to Right |
| Maximum tube diameter | 16" (406mm) |
| Minimum tube diameter | 4" (114mm) |
| Maximum wall thickness | 1/2" (12.7mm) |
| Minimum wall thickness | .125" (3mm) |
| Maximum material yield | 60,000 PSI |
| Maximum mill speed | 60 FPM (18.7 MPM) |
| Upper driven spindle diameter | 9-1/2" |
| Lower driven spindle diameter | 8" |
| Driven spindle diameter | 8" |
| Note | THE FOLLOWING ARE NOT INCLUDED |
| Overall dimensions | Multiple Pieces, 7 Truckloads |
| Approximate weight | 115,000 Lbs. |
Description
Maximum D/T Ratio: 60:1 Minimum D/T Ratio: 10:1 ENTRY EQUIPMENT NOT INCLUDED Forming Mill: (1) Driven Pinch Roll Stand, 51" Roll Space (2) 30 HP DC Motors (1) Double Gearbox 1:71 Ratio (1) Preform Entry Guide (1) Driven Breakdown Stand (Bottom Driven), 51" Roll Space (1) 60 HP DC Motor (1) Single Gearbox 1:70.582 Ratio (1) Forming Cage 25' Long x 7' Wide x 7'8" High (3) Driven Fin Stands w/Side Rolls 16-1/2" Roll Space (6) 60 HP DC Motors (3) Double Gearboxes 1:70.582 Ratio Welding Section: (1) Seam Guide Stand (1) Weld Pressure Unit, 4-Roll Type (4) Extra Weld Pressure Units, 3-Roll Type (1) Double Scarfing Unit (1) Bead Winder COOLING SECTION NOT INCLUDED Sizing Section: (4) Driven Sizing Stands w/Side Rolls 16-1/2" Roll Space Driven Spindle Diameter: 8" (8) 60 HP DC Motors (4) Double Gearboxes 1:70.582 Ratio (1) Turkshead/Straightener, 4-Roll w/Up & Down Adjustment w/Horizontal Adjustment w/Rotary Adjustment (27) Sets of Horizontal Roll Clevises for Fin & Sizing Sections Cut-Off or Runout Electrical Drive or Controls Roll Tooling
