60" x 20,000 Lb. Rowe Cut to Length Line (Used)

Specifications:

Manufacture: Rowe

Year Manufactured: 1979 (Herr-Voss Leveler: 1979, Wysong Shear 1979)

Direction: Right to Left

Material: Stainless, Aluminum, Painted Alum/Carbon

Coil Weight: 20,000 Lbs.

Coil Width: 24" min, 60" max.

Max. Coil O.D.: 72"

Min Coil O.D.: 26"

Coil I.D. : 20"

Gauge Range:

   0.024" - 0.105" Stainless Steel

   0.024" - 0.140" Aluminum

Line Speed: 160 fpm Max

Electrical Supply: 460V/3Ph/60Hz

Stack Lengths: 36"-168"

Stack Height: 13" Max. w/ Skid

Max. Pallet Weight: 5,000 Lbs.

SPV/Paper Application: Yes

Equipment List

Entry Coil Car

Single Mandrel Uncoiler 20,000 lbs Capacity

Peeler Table

Herr-Voss 6-HI Leveler (19 Rolls, 1.75" Work Roll Dia.) 150 HP Motor

Hump Table

SPV & Paper Application Unit

Wysong Shear

Belt Conveyor w/ Sheet Length Control Unit

Drop Stacker w/ Backstop

Side Discharge Chain Conveyors w/ Skid Loading Area

Packaging Table

Hydraulic units

Spare Parts Including One (1) Set of Leveler Work Rolls & Back-Up Bearings

Electrical package (operator stations, controls panels, etc.)

460V /3-ph/ 60 Hz
