67" W (1710 mm) x .009"-.079" (.23 mm-2 mm) x 20 Ton Color Coating Line (Used)

Capacity: 160,000(Ton / Year)

Manufacturer: 1999 by Jugairo, Shut Down in Sept, 2020

Product: Polyester, Silicon Polyester, PVDF, Highpolymer Polyester

Width: 67" W (1710 mm)

Coil Thickness: .009"-.079" (.23 mm-2 mm)

Coil Weight: 20 Ton

Material: CR, GI, EGI, SUS, Al

Line Length: (m) 248 Meter, Width : 30 Meter

Height: 21 Meter ( Under Ground 6.5 Meter + Over the Floor 14.5 Meter)

Coating Type: 2 Coat 2 Bake

  Coater: Prime  3 Head (Top 2 / Back 1)

        Finish  4 Head (Top 2 / Back 2)

  Oven: Prime  Length : 45m / : Max. 470?

      Finish  Length: : 52m / : Max. 470?

Product:

           - Polyester        - Si-Polyester

           - Modified Polyester    - Hi-Polymer

           - PVdF             - Aluminum coated

           - House Home Usage Black Color

Line Speed: 126 m/min. Max

Oven: Catenary Type

Chemi Coater: Vertical Roll Type

Welder : Mash Seam Welder

Oven Heating: Direct Heat Hot Air Recirculation
