1500mm x 6mm x 50,000# Rotary Shear Cut-to-Length Line

Specifications:

Min/Max thickness: 1mm-6 mm

Max Width: 1500 mm

Speed:40 m/min

Shear type: Rotary shear

Leveller:6 HI (8+7=15 Rolls)

Material: St 37

400V/50 Hz, 230V/ 50 Hz / 24 V DC

Hydraulic pressure 120 ba bar

Material: St37

Thickness: 1-6 mm

Width: 500-1500 mm

Coil Weight: 25 Tons

Min/Max Thickness: 1mm-6 mm

Min/Max Width: 500mm-1500 mm

Width Min/Max: 500mmx1500 mm

Length Min/Max: 500mm x 12000 mm

Sheet Dimension: 500mmx500 mm (Min) 1500x600 mm (Max)

Package Size: 1500mm x 6000 mm

Equipment List:

Coil Car

Uncoiler support arm

Uncoiler and overprint

Peleer table and top pressure

Pinch Roll

Pre-Straightening

Scrap Shears

Transition Rollers

Side Guide

Leveler 6HI (8+7 rollers)

Roller transfer table

Side Guide

Measuring Roller

Rotary Shear

Belt conveyor

Stack 12 mt

Stack Conveyor

Exit Conveyor
